Fortinet FortiGate Rugged 60F
Integrated Threat Management for Front Line Locations

Fortinet Fortigate 60F Rugged Appliance


Fortinet Products
FortiGateRugged-60F
Fortinet FortiGate Rugged 60F Firewall
Ruggedized, 4 x GE RJ45 Switch ports, 2 x Shared Media pairs (Including 2 x GE RJ45 ports, 2 x SFP slots). 1x RJ45 by-pass can be set up between WAN1 and PORT4. DB9 Serial
*Backorder
#FGR-60F
Get a Quote!
FortiGateRugged-60F 24x7 FortiCare Contract
FortiGateRugged-60F 1 Year FortiCare Premium Support
#FC-10-0069F-247-02-12
List Price: $439.40
Our Price: $380.43
FortiGateRugged-60F 3 Year FortiCare Premium Support
#FC-10-0069F-247-02-36
List Price: $1,318.20
Our Price: $1,141.30
FortiGateRugged-60F 5 Year FortiCare Premium Support
#FC-10-0069F-247-02-60
List Price: $2,197.00
Our Price: $1,902.16
FortiGateRugged-60F Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP)
FortiGateRugged-60F Hardware plus 1 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP)
#FGR-60F-BDL-950-12
List Price: $3,625.05
Our Price: $2,672.02
FortiGateRugged-60F Hardware plus 3 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP)
#FGR-60F-BDL-950-36
List Price: $6,481.15
Our Price: $4,777.26
FortiGateRugged-60F Hardware plus 5 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP)
#FGR-60F-BDL-950-60
List Price: $9,337.25
Our Price: $6,882.49
FortiGateRugged-60F Hardware plus 24x7 FortiCare and FortiGuard SMB Protection
FortiGateRugged-60F Hardware plus 1 Year FortiCare Premium and FortiGuard SMB Protection
#FGR-60F-BDL-879-12
List Price: $3,844.75
Our Price: $2,833.97
FortiGateRugged-60F Hardware plus 3 Year FortiCare Premium and FortiGuard SMB Protection
#FGR-60F-BDL-879-36
List Price: $7,140.25
Our Price: $5,263.08
FortiGateRugged-60F Hardware plus 5 Year FortiCare Premium and FortiGuard SMB Protection
#FGR-60F-BDL-879-60
List Price: $10,435.75
Our Price: $7,692.19
FortiGateRugged-60F Hardware plus 24x7 FortiCare and FortiGuard Enterprise Protection
FortiGateRugged-60F Hardware plus 1 Year FortiCare Premium and FortiGuard Enterprise Protection
#FGR-60F-BDL-811-12
List Price: $3,954.60
Our Price: $2,914.94
FortiGateRugged-60F Hardware plus 3 Year FortiCare Premium and FortiGuard Enterprise Protection
#FGR-60F-BDL-811-36
List Price: $7,469.80
Our Price: $5,505.99
FortiGateRugged-60F Hardware plus 5 Year FortiCare Premium and FortiGuard Enterprise Protection
#FGR-60F-BDL-811-60
List Price: $10,985.00
Our Price: $8,097.04

Click here to jump to more pricing!

Live Demo! Click here to load

Overview:

While traditional security solutions are designed and intended for the world of offices and corporations, the FortiGate Rugged Series offers industrially-hardened, all-in-one security appliance that delivers specialized threat protection for securing critical industrial and control networks against malicious attacks.

Ruggedized Protection for Harsh Environments

The ruggedized FortiGate meets all required performance and reliability standards for operating in demanding industrial settings. It was designed from the outset to operate reliably in harsh electrical and environmental conditions, including those with high levels of electrical and radio frequency interference and at wide ambient temperature ranges.

Industrial Network Security

Fortinet’s FortiOS operating system running on the ruggedized platform provides specialized protections for industrial networks such as antivirus and Intrusion Protection (IPS).

Features & Benefits

  • Ruggedized design — fanless and use of robust components ensure reliable operation in harsh industrial environments.
  • Consolidated Security Architecture - FortiGate running FortiOS consolidated security offers better protection and lower cost of ownership than multiple point products. Coupled with FortiGuard Industrial Security Service, it ensures that critical networks receive real-time protection.
  • SD-WAN Capable — Supports reliable connectivity with lower costs via SD-WAN technologies.
  • Ease of Management - Robust management systems that allow rapid provision and deployment, monitoring of device and threat status while providing actionable reports.
Firewall Performance IPsec VPN Throughput GE RJ45 Interfaces
30D 900 Mbps 45 Mbps 4
35D 550 Mbps 45 Mbps 3
60F 6 Gbps 3.5 Gbps 4
FGR-60F-3G4G 5.95 Gbps 3.5 Gbps 4

Hardware:

FGR-30D

FortiGate Rugged 30D

  1. 1x USB Port
  2. 4x GE RJ45 Ports
  3. 2x GE SFP Slots
  4. 2x DB9 Serial Interface/Console

FGR-35D

FortiGate Rugged 35D

  1. 3x GE RJ45 Po

FGR-60F / FGR-60F-3G4G

FortiGate Rugged 60F Hardware

  1. 4x GE RJ45 Ports
  2. 1x Bypass GE RJ45 Port Pair (WAN1 & Port4, default setting)*
  3. 2x GE RJ45/SFP Shared Media Pairs
  4. Integrated 3G4G Modem
*NOTE: WAN1/WAN2 and SFP1/SFP2 are shared interfaces

Fortinet Fabric Security:

Fabric Security

Security Fabric

The industry’s highest-performing cybersecurity platform, powered by FortiOS, with a rich ecosystem designed to span the extended digital attack surface, delivering fully automated, self-healing network security.

  • Broad: Coordinated detection and enforcement across the entire digital attack surface and lifecycle with converged networking and security across edges, clouds, endpoints and users
  • Integrated: Integrated and unified security, operation, and performance across different technologies, location, deployment options, and the richest Ecosystem
  • Automated: Context aware, self-healing network & security posture leveraging cloud-scale and advanced AI to automatically deliver near-real-time, user-to-application coordinated protection across the Fabric

FortiOS™ Operating System

FortiOS, Fortinet’s leading operating system enable the convergence of high performing networking and security across the Fortinet Security Fabric delivering consistent and context-aware security posture across network endpoint, and clouds. The organically built best of breed capabilities and unified approach allows organizations to run their businesses without compromising performance or protection, supports seamless scalability, and simplifies innovation consumption. The release of FortiOS 7 dramatically expands the Fortinet Security Fabric’s ability to deliver consistent security across hybrid deployment models consisting on appliances, software and As-a-Service with SASE, ZTNA and other emerging cybersecurity solutions.

Services

FortiGuard™ Security Services

FortiGuard Labs offers real-time intelligence on the threat landscape, delivering comprehensive security updates across the full range of Fortinet’s solutions. Comprised of security threat researchers, engineers, and forensic specialists, the team collaborates with the world’s leading threat monitoring organizations and other network and security vendors, as well as law enforcement agencies.

FortiCare™ Services

Fortinet is dedicated to helping our customers succeed, and every year FortiCare services help thousands of organizations get the most from their Fortinet Security Fabric solution. We have more than 1,000 experts to help accelerate technology implementation, provide reliable assistance through advanced support, and offer proactive care to maximize security and performance of Fortinet deployments.

Specifications:


FGR-30D FGR-35D FGR-60F FGR-60F-3G4G
Interfaces and Modules
GE RJ45 Interfaces 4 3 4 4
Bypass GE RJ45 Port Pair* 1 1
GE SFP Slots 2 -
GE RJ45/SFP Shared Media Pairs 2 2
DB9 Serial Interface 2 1 1
USB (Client / Server) 1 1 1
RJ45 Console Port 1 1
Trusted Platform Module (TPM) Yes Yes
Cellular Modem 3G4G / LTE 3G4G / LTE
Included Transceivers None None None None
System Performance and Capacity
IPv4 Firewall Throughput (1518 UDP) 900 Mbps** 550 Mbps** 6/6 Gbps 5.95 Gbps
Firewall Latency (64 byte, UDP) 70 μs 90 μs 3.10 μs 3.10 μs
Firewall Throughput (Packets Per Second) 87 Kpps 52.5 Kpps 8.9 Mpps 8.9 Mpps
Concurrent Sessions (TCP) 750,000 750,000 600,000 600,000
New Sessions/Sec (TCP) 5,000 5,000 19,000 19,000
Firewall Policies 5,000 5,000 5,000 5,000
IPsec VPN Throughput (512 byte) 45 Mbps 45 Mbps 3.5 Gbps 3.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 200 200 200 200
Client-to-Gateway IPsec VPN Tunnels 250 250 500 500
SSL-VPN Throughput 25 Mbps 25 Mbps 400 Mbps 400 Mbps
Concurrent SSL-VPN Users (Recommended Maximum) 80 80 100 100
SSL Inspection Throughput (IPS, avg. HTTPS) 50 Mbps 55 Mbps 460 Mbps 460 Mbps
SSL Inspection CPS (IPS, avg. HTTPS) 75 75 300 300
SSL Inspection Concurrent Session 45,000 45,000 70,000 70,000
Application Control Throughput (HTTP 64K) 210 Mbps 230 Mbps 1.3 Gbps 1.3 Gbps
Virtual Domains (Default / Maximum) 5 / 5 5 / 5 10 / 10 10 / 10
Maximum Number of FortiAPs (Total / Tunnel) 2 / 2 2 / 2 30 / 10 30 / 10
Maximum Number of FortiTokens 20 20 500 500
Maximum Number of FortiSwitches 8 8 16 16
High Availability Configurations Active-Active, Active-Passive, Clustering Active-Active, Active-Passive, Clustering Active-Active, Active-Passive, Clustering Active-Active, Active-Passive, Clustering
System Performance — Enterprise Traffic Mix
IPS Throughput 180 Mbps 210 Mbps 950 Mbps 950 Mbps
NGFW Throughput 45 Mbps 65 Mbps 550 Mbps 550 Mbps
Threat Protection Throughput 16 Mbps 16 Mbps 500 Mbps 500 Mbps
Dimensions and Power
Height x Width x Length (inches) 5.49 x 4.13 x 2.36 3.07 x 10.04 x 10.04 1.68 x 8.50 x 6.50 1.68 x 8.50 x 6.50
Height x Width x Length (mm) 139.5 x 105 x 60 78 x 255.09 x 255.09 42.7 x 216 x 165 42.7 x 216 x 165
Weight 1.46 lbs (0.668 kg) 3.986 lbs (1.808 kg) 3.85 lbs (1.75 kg) 3.85 lbs (1.75 kg))
Form Factor Desktop/DIN/Wall Mount Outdoor mountable Desktop Desktop/DIN/Wall Mount
IP Rating IP20 IP67 IP20 IP20
Power Supply Dual input, total 6 pin terminal block (12–48V DC) AC adapter not included.* Terminal block (12–48V DC), DC cables are not included Terminal block, supports negative (+12V to +125V DC) and positive ground (-12V to -125V DC) sources,
cables are not included
Terminal block, supports negative (+12V to +125V DC) and positive ground (-12V to -125V DC) sources,
cables are not included
Power Consumption (Average / Maximum) 15.55 W / 15.92W 10.2 W / 10.5 W 15 W / 21 W 17 W / 24W
Maximum Current 1.19A 0.83A 12V DC / 2A 12V DC / 2A
Heat Dissipation 54.29 BTU/h 35.81 BTU/h 72 BTU/h 82 BTU/h
Operating Environment and Certifications
Operating Temperature -40–158°F (-40–70°C) -40–140°F (-40–60°C) -40–167°F (-40–75°C) -40–167°F (-40–75°C)
Storage Temperature -58–185°F (-50–85°C) -58–185°F (-50–85°C) -40–167°F (-40–75°C) -40–167°F (-40–75°C)
Humidity 5–95% non-condensing 5–95% non-condensing 5–95% non-condensing 5–95% non-condensing
Operating Altitude Up to 7,400 ft (2,250 m) Up to 7,400 ft (2,250 m) Up to 7,400 ft (2,250 m) Up to 7,400 ft (2,250 m)
Compliance FCC Part 15 Class A, RCM VCCI Class B, CE, UL/cUL, CB FCC Part 15 Class A, RCM VCCI Class B, CE, UL/cUL, CB FCC Part 15 Class A, RCM VCCI Class B, CE, UL/cUL, CB FCC Part 15 Class A, RCM VCCI Class B, CE, UL/cUL, CB
Certifications 61850-3 and IEEE 1613 Emission Compliant 61850-3 and IEEE 1613 Emission Compliant IEC 61850-3 and IEEE 1613 Certified IEC 61850-3 and IEEE 1613 Certified

* Default bypass pair configuration is WAN1 and Port4

** Measured using 1518 byte UDP packets

Documentation:

Download the Fortinet FortiGate Rugged Series Datasheet (PDF).
