Fortinet FortiAP 433G Access Point
4x4 Wi-Fi 6E, Indoor wireless AP: Tri radio, External antenna (6GHz antennas integral to unit), >2 x 5GE RJ45 ports

Fortinet FortiAP 433G

Coming soon with no current ETA


Fortinet Products
Fortinet FortiAP 433G Access Point
FortiAP-433G
Indoor Wireless AP - Tri radio (Wi-Fi-6E IEEE 802.11ax Tri-band 2.4/5/6GHz and dual 5G operation 4+4+4 4 streams 3 radios), external antennas, 2x 5G Base-T RJ45, BT/BLE, 1x Type A USB, 1x RS-232 RJ45 Serial Port. Ceiling/wall mount kit included. For power order: 802.3bt PoE injector or AC adapter SP-FAP400-PA. Region Code A
#FAP-433G-A
List Price: $1,200.00
Our Price: $1,038.96

Click here to jump to more pricing!

Overview:

FortiAP™ access points are managed centrally by the integrated WLAN controller of any FortiGate® security appliance or through the FortiLAN Cloud provisioning and management portal. With the integration of the wireless controller functionality into the market-leading FortiGate appliance, these APs are perfect for campus and branch deployments. Fortinet’s Security Fabric enables you to easily manage wired and wireless security from a Single-pane-ofglass management console and protects your network from the latest security threats.

Unified Management

Unified management console simplifies operations, ensuring consistency in effective policy enforcement and compliance.

Advanced Security Protection

Wireless LAN security done right, from the leader in network security. Integrated Firewall, IPS, Application Control, and Web Filtering protect the wireless LAN from the latest security threats.

Built-in Wi-Fi Security

Protects the network from advanced wireless threats and satisfies PCI DSS compliance.

Highlights - FortiAP 431G and 433G

These high performing enterprise class extended frequency band Wi-Fi 6E indoor APs provide three radios and four spatial streams. This access point supports the 6 GHz band, OFDMA, and a 5 Gigabit Ethernet port. The AP can provide 24/7 scanning across all bands while still providing access on both the 2.4 GHz and 5 GHz bands or 2.4 Ghz and dual 5 GHz service or the AP can be configured to provide simultaneous access on 2.4 GHz, 5 GHz, and the 6 GHz bands. The integrated BLE/ ZigBee radio can be used for beacons and locationing applications.

Wi-Fi 6E | Tri-Radio 2.4 + 5GHz + 5GHz / 6GHz / Scanning | 8 Internal Antennas / 4 External RPSMA Connectors + 4 External Permanently attached Antennas


Specifications:


  FORTIAP 431G FORTIAP 433G
Hardware
Hardware Type Indoor AP
Number of Radios 3 + 1 BLE
Number of Antennas Internal: x4 Dual band Wi-Fi + x4 Tri-band Wi-Fi & Scanning + 1 Single band 2.4GHz BLE/ ZigBee External: x4 Dual band Wi-Fi + x4 Tri-band Wi-Fi & Scanning Internal: 1 Single band 2.4GHz BLE/ZigBee
Antenna Type and Peak Gain PIFA antenna. Dual band: 4.0 dBi for 2.4GHz, 5.6 dBi for 5 GHz Tr-band: 4.0 dBi for 2.4GHz, 6.0 dBi for 5 GHz & 5.7dBi for 6GHz band BLE antenna: 5.1dBi for 2.4Ghz Omni Directional antenna. Dual band: 5.0 dBi for 2.4GHz, 5.0 dBi for 5 GHz Tr-band: 5.0 dBi for 2.4GHz, 5.0 dBi for 5 GHz & 4.0dBi for 6GHz band BLE PIFA antenna Single band: 4.0dBi for 2.4GHz
Frequency Bands (GHz) 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850, 5.925–6.425, 6.425–6.525, 6.525–7, 5.925–6.875, 6.875–7.125
Radio 1 Capabilities Frequency band: 2.4GHz
Channel width: 20/40MHz
Modulation: BPSK, QPSK, 64/256/1024 QAM
MIMO Chains: 4x4 Service
Radio 2 Capabilities Frequency band: 5.0GHz
Channel width: 20/40/80/80+80MHz
Modulation: BPSK, QPSK, 64/256/1024 QAM
MIMO Chains: 4x4 Service
Radio 3 Capabilities Frequency bands: 6.0GHz
Channel width: 20/40/80/160MHz
Modulation: BPSK, QPSK, 64/256/1024 QAM
MIMO Chains: 4x4 Service and 2x2 scanning
Maximum Data Rate Radio 1: up to 1148 Mbps
Radio 2: up to 2402 Mbps
Radio 3: : Up to 4804 Mbps
Bluetooth Low Energy Radio Bluetooth scanning and iBeacon advertisement @ 10 dBm max TX power
Interfaces x2 100/1000/2500/5000 Base-T RJ45, 1 Type 3.0 USB, 1 RS-232 RJ45 Serial Port
Power over Ethernet (PoE) 1 802.3bt PoE default or x2 802.3at PoE (Dual PoE current sharing)
Simultaneous SSIDs Up to 24
EAP Type(s) EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST
User/Device Authentication WPA™, WPA2™, and WPA3™ with 802.1x or preshared key, WEP, Web Captive Portal, MAC blocklist & allowlist
Maximum Tx Power (Conducted) Radio 1: 2.4GHz: 27 dBm / 501 mW (4 chains combined)
Radio 2: 5GHz: 26 dBm / 400 mW (4 chains combined)
Radio 3: 6GHz: 24 dBm 251 mW (4 chains combined @ 160MHz BW)
Kensington Lock Yes
IEEE Standards 802.11a, 802.11b, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.11ax, 802.1X, 802.3ad, 802.3at, 802.3bt, 802.3az
SSID Types Supported Local-Bridge, Tunnel, and Mesh
Per Radio Client Capacity Up to 512 clients per radio (Radio1, Radio2 and Radio3)
Cellular Co-existence Yes
LED Off Mode Yes
Advanced 802.11 Features
OFDMA Yes
Spatial Reuse (BSS Coloring) Yes
UL MU-MIMO Yes
DL-MU-MIMO Yes
Enhanced Target Wake Time (TWT) Yes
ZeroWait DFS No
Wireless Monitoring Capabilities
Rogue Scan radio modes Background, Dedicated
WIPS / WIDS radio modes Background, Dedicated (recommended)
Packet Sniffer Mode Yes
Spectrum Analyzer Yes
Dimensions
Length x Width x Height 8.85x 8.85 x 2.12 inches 225.0x 225.0 x 54.0 mm
Weight 3.05 lbs (1.4 kg) 3.05 lbs (1.4 kg)
Mounting Options Ceiling, T-Rail, and Wall
Included Accessories Standard Mount kit for Ceiling, T-Rail, and Wall
Environment
Power Supply SP-FAP400-PA-XX or 802.3bt PoE. Also supports Dual PoE sharing with 2x 802.3at PoE (GPI-130) or Single 802.at PoE (GPI-130) with No USB and reduced Transmit power
Power Consumption (Maximum) 31.7 Watts
Humidity 5 - 90% non condensing
Operating / Storage Temperature 32°–122°F (0° - 50°C) / -22°–158°F (-30°–70°C)
Directives Low Voltage Directive • RoHS
UL2043 Plenum Material Yes
Mean Time Between Failures > 10 Years
IP Rating N/A
Surge Protection Built In Yes
Hit-less PoE Failover No
Certifications
WiFi Alliance Certified Yes
DFS CE
Warranty
Limited Lifetime Warranty Yes

Documentation:

Download the Fortinet FortiAP Series Datasheet (PDF).
