The FortiMail family of secure email appliances provide
an effective barrier against the ever-rising volume of spam,
maximum protection against sophisticated email attacks, and
features designed to facilitate regulatory compliance.
FortiMail offers both inbound and outbound scanning,
advanced antispam and antivirus filtering capabilities, IP
address black/white listing functionality, and extensive
quarantine and archiving capabilities. Three deployment
modes offer maximum versatility: transparent mode for
seamless integration into existing networks with no IP
address changes, gateway mode as a proxy MTA for existing
email gateways, or full email server functionality for SMBs
and remote offices.
- Layered protection (FortiGate + FortiMail) improves email security, separates low-latency perimeter and high-latency email functions for more efficient operation
- Advanced inspection capabilities and additional IP/antispam filtering functions improves protection against sophisticated email-based threats
- Stops spam before it consumes mail system and network resources, reducing capital expenditures on email functionality
- Advanced email content archiving, quarantining, and routing capabilities help achieve regulatory compliance
- Three modes of operation provide flexible deployment options (Transparent, Gateway, and Server)
- Turn-key deployment, integrated management, logging and reporting, and fully-automated security updates reduce IT management burden and operational expenses, with no per-user licensing fees
| FortiMail-100
 |
The FortiMail-100 delivers the complete
feature set of the FortiMail family in a
cost-effective platform, making it ideal for
Small Office/Home Office (SOHO) and Remote
Office/Branch Office (ROBO) applications. Its
all-in-one secure email server capability
reduces deployment and operational costs,
processing up to 54,000 emails per hour with
full antivirus and antispam filtering.
- Full inspection of up to 54,000 emails per hour
- Supports up to 200 server mode mailboxes
- 4 10/100 ports
- 1 x 250 GB 3.5" SATA drive
- High availability options
- Desktop form factor
|
| FortiMail-100C
 |
Designed for smaller networks and remote
locations, the FortiMail-100C delivers
the complete feature set of the FortiMail family
in a cost-effective platform. Its provides 1 TB
of storage for message archiving, eliminating
the need to acquire additional storage for
policy compliance. It can process up to 77,000
emails per hour with full antivirus and antispam
filtering.
- Full inspection of 77,000 emails per
hour
- Supports up to 200 server mode mailboxes
- 1 x 10/100
(Copper, RJ-45),
2 x 10/100/1000 (Copper, RJ-45)
- 1 TB storage
- Desktop form factor
|
| FortiMail-400
|
The
FortiMail-400, designing for medium-sized
enterprise installations, features a software
RAID (0 or 1) storage subsystem for reliable
archiving and logging, and offers global and
per-user spam policies for maximum configuration
flexibility. It can process 154,800 emails per
hour with full antivirus and antispam filtering.
- Full inspection of 154,800 emails per hour
- Supports up to 500 mail boxes in server mode
- 4 x 10/100 and 2 x 10/100/1000 ports
- 2 x 250 GB 3.5'' SATA drives
- High availability options
|
| FortiMail-400B
|
The
FortiMail-400B, designing for medium-sized
enterprise installations, features a software
RAID (0 or 1) storage subsystem for reliable
archiving and logging, and offers global and
per-user spam policies for maximum configuration
flexibility. It can process 185,400 emails per
hour with full antivirus and antispam filtering.
- Full inspection of
185,400 emails per hour
- Supports up to 500 mail boxes in server mode
- 4 x 10/100/1000 ports
- 2 x 500 GB 3.5'' SATA drives
- High availability options
|
|
FortiMail-2000A
 |
The
FortiMail-2000A, designing for large
enterprise installations, can process 371,500
emails per hour with full antivirus and antispam
filtering. Hardware RAID storage (1.5-terabyte
capacity), hot swappable/redundant power
supplies and fans, and high-availability options
ensure data integrity and reliability. Four
10/100/1000 ports allow connectivity to multiple
Internet connections.
- Full inspection of 371,500 emails per hour
- 4 10/100/1000 ports
- 6 x 250 GB 3.5" SATA drives (1.5 TB)
- Hardware RAID (0, 1, 5, 10 or 50)
- Redundant/hot-swappable power supplies and fans
- High availability options
|
|
FortiMail-2000B
 |
Designed for
global enterprises and service providers who
wish to provide mail domain protection, the
FortiMail-2000B can process up to 1.0
million emails per hour with full antivirus and
antispam filtering. It contains 2 TB of storage
(user-upgradable to 6 TB) and supports hardware
RAID storage. Its hot swappable/redundant power
supplies and high-availability options ensure
data integrity and reliability for high volume
messaging systems.
- Full inspection of 1.0 million emails
per hour
- 6 x
10/100/1000 Interfaces
(Copper, RJ-45)
- 2 x 1 TB (6 TB Optional) storage
- Hardware RAID: 1, 5, 10, 50, Hot Spare (Based
on Number of Drives)
- Redundant/hot-swappable power supplies and fans
- High availability options
|
|
FortiMail-4000A
|
The
FortiMail-4000A, designing for global
enterprises and telecommunications service
providers who wish to provide mail domain
protection, can process 467,000 emails per hour
with full antivirus and antispam filtering.
Hardware RAID storage (3-terabyte capacity), hot
swappable/redundant power supplies and fans, and
high-availability options ensure data integrity
and reliability.
- Full inspection of 467,000 emails per hour
- 2 10/100/1000 ports
- 12 x 250 GB 3.5" SATA drives (3.0 TB)
- Hardware RAID (0, 1, 5, 10 or 50)
- Redundant/hot-swappable power supplies and fans
- High availability options
|
|
FortiMail-5001A
 |
Designed for
global enterprises and service providers who
wish to provide mail domain protection for their
data center, the FortiMail-2000B can process up
to 1.1 million emails per hour with full
antivirus and antispam filtering. The
FortiMail-5001A integrates quickly and easily
with chassis-based FortiGate-5000 series
multi-threat security systems, and other 3rd
party ATCA chassis.
- Full inspection of 1.1 million emails per hour
-
2 10/100/1000 ports and
ASM-S08 (80GB storage) module
- 1 x 80 GB HDD (ASM Storage Module)
storage
- ATCA Chassis form factor
|
|
