Fortinet FortiAnalyzer 4000B Appliance
Centralized Logging, Analysis, and Reporting
| Fortinet Products | ||
|---|---|---|
| FortiAnalyzer-4000B | ||
| Fortinet FortiAnalyzer-4000B Appliance - Six (6) removable 1TB HDD, up to 6000 logs/sec, up to 2000 devices (any FortiGate model), rack mountable |
#FAZ-4000B Our Price: $39,995.00 |
|
| FortiAnalyzer-4000B Bundle | ||
| Fortinet FortiAnalyzer-4000B Appliance plus 8x5 Forticare and Vulnerability Management, 1 Year - Six (6) removable 1TB HDD, up to 6000 logs/sec, up to 2000 devices (any FortiGate model), rack mountable |
#FAZ-4000B-BDL Our Price: $49,994.00 |
|
Click here to jump to more pricing!
Overview:
For service providers and very large organizations, the FortiAnalyzer™-4000B appliance securely aggregates, analyzes, and reports on log data from gathered from Fortinet devices and other syslog-compatible devices. You can analyze and manage a wide range of data, including security events, network traffic, Web content, and email, to measure your security posture regulatory compliance.
FortiAnalyzer-2000B Features & Benefits:
- Secure data aggregation from multiple FortiGate® and FortiMail™ security appliances provides network-wide visibility
- Over 300 customizable reports help monitor and maintain identify attack patterns, acceptable use policies, and demonstrate policy compliance
- 6 TB of on-device log data capacity (expandable to 24 TB, 16TB file system) with built-in RAID storage options for policy compliance and forensic analysis
- Up to 6,000 logs/second with support for up to 2,000 devices.
- Data receive rates up to 24 Mbps for high bandwidth locations
- Network event correlation allows IT administrators to more quickly identify and react to network security threats across the network.
Enhanced Visibility With FortiAnalyzer Platforms
FortiAnalyzer platforms integrate network logging, analysis, and reporting into a single system, delivering increased knowledge of security events throughout a network. It provides organizations of any size with centralized security event analysis, forensic research, reporting, content archiving, data mining, malicious file quarantining and vulnerability assessment. Centralized collection, correlation, and analysis of geographically and chronologically diverse security data from Fortinet appliances and third-party devices deliver a simplified, consolidated view of your security posture.
The FortiAnalyzer family minimizes the effort required to monitor and maintain acceptable use policies, as well as identify attack patterns to help you fine tune your policies. In addition, FortiAnalyzer platforms provide detailed data capture for forensic purposes to comply with policies regarding privacy and disclosure of information
Security Event Information Management
You can put time back in your day by deploying a FortiAnalyzer platform into your security infrastructure, creating a single view of your security events, archived content, and vulnerability assessments. FortiAnalyzer platforms accept a full range of data from Fortinet solutions, including traffic, event, virus, attack, content filtering, and email filtering data. It eliminates the need to manually search multiple log files or manually analyze multiple consoles when performing forensic analysis or network auditing. A FortiAnalyzer platform’s central data archiving, file quarantine and vulnerability assessment functionality further reduce the amount of time you need to spend managing the range of security activity in your enterprise or organization.
Vulnerability Management
Fortinet offers an enhanced scanning capability that utilizes a dynamic signature dataset to detect devices on your network, catalog vulnerabilities, and recommend remediation. Additional capabilities include device discovery, mapping, asset definition and prioritization, and customized reporting. An optional Vulnerability Management subscription provides frequent updates developed by the FortiGuard Labs with up-todate vulnerability scan data to keep abreast of current threats.
Features & Benefits:
| Features: | Benefits: |
|---|---|
| Network Event Correlation | Allows IT administrators to more quickly identify and react to network security threats across the network. |
| Streamlined Graphical Reports | Provides network-wide reporting of events, activities and trends occurring on FortiGate® and third party devices. |
| Scalable Performance and Capacity | FortiAnalyzer family models support thousands of FortiGate and FortiClient™ agents. |
| Centralized Logging of Multiple Record Types | Including traffic activity, system events, viruses, attacks, Web filtering events, and messaging activity/data. |
| Seamless Integration with the Fortinet Product Portfolio | Tight integration maximizes performance and allows FortiAnalyzer resources to be managed from FortiGate or FortiManager™ user interfaces. |
| Choice of Collector or Analyze mode | Can be optimized for either Store & Forward or Analytic operations. |
Technical Specifications:
| Model: | FAZ-100C | FAZ-400C | FAZ-1000C | FAZ-2000B | FAZ-4000B |
|---|---|---|---|---|---|
 |
 |
 |
 |
 |
|
| Hardware Specifications | |||||
| Security Hardened Platform | Yes | Yes | Yes | Yes | Yes |
| 10/100/1000 Ethernet | 2 | 4 | 4 | 6 | 2 |
| 10/100 Ethernet | 1 | 0 | 0 | 0 | 0 |
| 1GbE SPF | 0 | 0 | 0 | 0 | 2 |
| Number of Hard Drives | 1 | 1 | 1 (Three Drives Optional) | 2 (Four Drives Optional) | 6 (Eighteen Drives Optional) |
| Total Hard Drive Capacity | 1 TB | 2 TB | 1.0 TB (4 TB Optional) | 2.0 TB (6 TB Optional) | 6 TB (P24 TB Optional, 16 TB File System) |
| RAID Storage Management | No | No | No (Yes with Optional Drives 0, 1, 10) | Yes (0, 1, 5, 10, 50) | Yes (0, 1, 5, 6, 10, 50, 60: default is 50) |
| Redundant Hot Swap Power Supplies | No | No | No | Yes | Yes |
| System Performance | |||||
| Log Performance (Logs/Sec) | Up to 200 | 625 | Up to 1,000 | Up to 3,000 | Up to 6,000 |
| Data Receive Rate | 800 Kbps | 2.5 Mbps | 4 Mbps | 12 Mbps | 24 Mbps |
| Number of Licensed Network Devices1 | 100 | 200 | 2,000 | 2,000 | 2,000 |
| Number of FortiClient Devices | 100 | 2,000 | No Restriction | No Restriction | No Restriction |
| Number of ADOMs Supported | 1 | 10 | 50 | 100 | 250 |
| FortiGate Models Supported | All Models | All Models | All Models | All Models | All Models |
| Dimensions | |||||
| Height | 1.75 in (4.4 cm) | 1.7 in (4.4cm) | 1.7 in (4.3 cm) | 3.4 in (8.6 cm) | 6.89 in (17.5cm) |
| Width | 15 in (38 cm) | 17.1 in (43.5 cm) | 17.1 in (43.4 cm) | 17.4 in (44.3 cm) | 19.09 in (48.5 cm) |
| Length | 6.3 in (16 cm) | 14.3 in (36.4 cm) | 24.7 in (62.7 cm) | 26.8 in (68.1 cm) | 27.17 in (69.0 cm) |
| Weight | 4 lbs (1.8 kg) | 14.7 lbs (6.7 kg) | 35.0 lbs (15.9 kg) | 57.5 lbs (26.1 kg) | 94.5 lbs (43kg) |
| Rack Mountable | Yes | Yes | Yes | Yes | Yes |
| Regulatory | |||||
| AC Power Required | 100-240 VAC, 50-60 Hz, 1.5 Amp (Max) | 100-240 VAC, 50-60 Hz, 4 Amp (Max) | 100-240 VAC, 50-60 Hz, 7 Amp (Max) | 100-240 VAC, 50-60 Hz, 8 Amp (Max) | 100-240 VAC, 50 - 60 Hz, 5.5 - 11.5 Amps (Max) |
| Power Consumption (AVG) | 56W | 100W | 189W | 152W | 420W for 6 HDD |
| Heat Dissipation | 190.4 BTU | 411 BTU | 643.6 BTU | 519 BTU | 1433.7 BTU (6 drives) 2034.6 BTU (12 drives) |
| Operating Temperature | 32 - 104 deg F (0 - 40 deg C) | ||||
| Storage Temperature | -13 - 158 deg F (-25 - 70 deg C) | ||||
| Humidity | 5 to 95% non-condensing | ||||
| Compliance | |||||
| FCC Class A Part 15, UL/CUL, C Tick, CE, VCCI | |||||
1A licensed network device is defined as:
- One (1) FortiGate device without Virtual Domain (VDOM) mode enabled, or
- One (1) VDOM if FortiGate device is running in multiple VDOM mode or
- One (1) Third-party SYSLOG compatible device
Graphic Reporting:
FortiAnalyzer systems empower the network or security administrator with the knowledge needed to secure their networks through a comprehensive suite of standard graphical reports and the total flexibility to customize custom reports. Network knowledge can be archived, filtered and mined for compliance or historical analysis purposes.
Grandular Information:
The FortiAnalyzer User Interface (UI) enables administrators to drill deep within security log data to provide the granular level of reporting necessary to understand what is happening on your network. Historical or real-time views allow administrators to analyze log and content information, as well as network traffic. The advanced forensic analysis tools allow the administrator to track user activities to the content level.
Real-Time Log Viewer:
The ability to monitor network, traffic and user events in real-time or browse historical for specific events provides powerful insight into network security threats, performance and user behavior.
Supported Devices:
- FortiGate Multi-Threat Security Systems
- FortiMail Messaging Security Systems
- FortiClient Endpoint Security Suite
- FortiManager Centralized Management
- Any Syslog-Compatible Device
FortiAnalyzerOS provides the following features:
| FortiAnalyzerOS Security Services | ||
|---|---|---|
General System Functions
DLP Archive / Data Mining
Network Analyzer
|
Log Analysis & Reporting
Forensic Analysis
Log Browser And Real-Time Log Viewer
|
Vulnerability and Compliance Management Scanning
FortiAnalyzer systems empower the network or security administrator with the knowledge needed to secure their networks through a comprehensive suite of standard graphical reports and the total flexibility to customize custom reports. Network knowledge can be archived, filtered and mined for compliance or historical analysis purposes. Granular Information The FortiAnalyzer User Interface (UI) enables administrators to drill deep within security log data to provide the granular level of reporting necessary to understand what is happening on your network. Historical or real-time views allow administrators to analyze log and content information, as well as network traffic. The advanced forensic analysis tools allow the administrator to track user activities to the content level. Real-Time Log Viewer The ability to monitor network, traffic and user events in real-time or browse historical data for specific events provides powerful insight into network security threats, performance and user behavior. Supported Devices
|
Services & Support:
FortiGuard Security Subscription Services
FortiGuard Security Subscription Services deliver dynamic, automated updates for Fortinet products. The Fortinet Global Security Research Team creates these updates to ensure up-to-date protection against sophisticated threats. Subscriptions include antivirus, intrusion prevention, web filtering, antispam, vulnerability and compliance management, application control, and database security services.
FortiCare Support Services
FortiCare Support Services provide global support for all Fortinet products and services. FortiCare support enables your Fortinet products to perform optimally. Support plans start with 8x5 Enhanced Support with "return and replace" hardware replacement or 24x7 Comprehensive Support with advanced replacement. Options include Premium Support, Premium RMA, and Professional Services. All hardware products include a 1-year limited hardware warranty and 90-day limited software warranty.
Documentation:
Download the Fortinet FortiAnalyzer Datasheet (PDF).
